Challenger 9K Low Ceiling 2-Post Lift – CLFP9

Challenger CLFP9 9,000 lb Low-Ceiling Drive-On Pad Two-Post Lift

The Challenger CLFP9 is a 9,000 lb drive-on pad lift designed for fast vehicle spotting in express service bays. Its low-profile platform, adjustable height options, reinforced ramps, and durable equalization system support efficient service for a wide range of vehicles.

Challenger CLFP9 Features

• 9,000 lb lifting capacity
• Drive-on express pad for quick vehicle spotting
• Low-profile platform design
• Flip-up access ramps for longer wheelbase vehicles
• 48 in elongated carriage
• Oversized 5 in pulley and heavy-duty 5/16 in cable
• Padded overhead shutoff system
• Jacketed single-point lock release
• Dual integrated rubber door guards
• ALI/ETL certified

Challenger CLFP9 Specifications

• Rise Height: 70 in
• Overall Height: 140 in
• Optional 2 ft or 3 ft extensions
• Overall Width: 138.5 in
• Drive-Through Clearance: 90 in
• Platform Height: 2.25 in
• Platform Width: 24 in
• Platform Length: 58, 66.5, or 75 in
• Inside Columns: 110 in
• Motor: 2 HP, 208-230V, 60Hz, single phase
• Rise Speed: approximately 38 seconds
• Required Ceiling Height: 12 ft
• Available colors: red, blue, or black
